Laminar Air Flow (Vertical)

Biotechnologies Inc is a leading manufacturer, supplier & exporter of laminar air flow in Delhi.

Laminar airflow vertical stands tall where air steams cross over is literally not seen. The laminar generated uniform speed moving in one direction all over the laminar airflow cabinet. Thus creating a sterile working environment helps us to carry out specialized particle-free work in Bio-Gene Laminar Air Flow Vertical.

  • Applications
  • Features
  • Control
  • Construction
  • Specification

Vertical Laminar air flow is designed for Industrial, Pharma, Biotech and Medical research applications.

  • 99.99% Particle Removal Class 100 HEPA Filter
  • Air Velocity Control.
  • Clean air velocity 90±20 FPM at the outlet of HEPA filters
  • UV, FL Lamp.
  • Filter Replacement Warning Lamp.
  • Slide Type Door with acrylic/tempered safety glass, durable powder coated body and stainless steel work table
  • Built-In Lamps and Utilities UV and Fluorescent Lamp, air and gas cock, power consent
  • Whole cabinet made of stainless steel.
  • Air/Gas Regulator.
  • Pressure monitor from 0-25 mm


1. Large Display of laminar air flow features a Power-on-switch, 16 x 2 LCD Alphanumeric display showing the controlling of the different parameters with touch keys to control the different parameters.

2. The Menu Driven system allows the user to set multiple parameters easily.
3. U.V light Age calculation.
4. Simple to use and operate keys for U.V light On/Off ,F.L Light On/Off, Blower on/Off ,Alarm key.
5. Timers for U.V light operation up to 99mins
6. Timer for Blower operation up to 99:99 hrs
7. Alarm indication on timer completion process.
8. Password protection
9. Led indication for all outputs.
10. U.V light and Blower Output will automatically get switched off after their respective set time is over.

Shown below is the back connections strip cum wiring diagram of laminar controller.

1. LCD Display: Airflow velocity, UV timer, UV work time, system work time, real time

2. Waterproof socket : 2 waterproof sockets are located in the side panel, for optimum convenience of using small devices inside the cabinet

3. UV lamp: Emission of 30W 254nanometers for most efficient decontamination

4. Gas Tap:

5. Side glass window: The transparent side glass windows maximize light and visibility inside the cabinet, providing a bright and open working environment.

  • Designed so as to meet the requirements of US Federal Standards 209 B providing particle free air to meet class 100 (Class Conditions).
  • Cabinets is fabricated out of Stainless steel.
  • Interior surfaces are complete stainless steel.
  • whole cabinet is Stainless Steel 304 grade.
  • Side panels are made out of thick transparent flexi glass.
  • Unit is fitted with Pre-filter and HEPA Filter.
  • Air is drawn through pre filter and is made to pass through highly effective HEPA filters having efficiency rating as high as 99.99% with Hot DOP, thus retaining all air borne particles of size 0.2 micron and larger.
  • Using a dynamic machine the blower and motor assembly is statically & dynamically balanced.
  • Motor of 1/5 H.P. Capacity operates with minimum noise level.
  • Low sound level (~65 decibel)
  • Working area is illuminated by fluorescent lighting fitted to the unity.
  • Laminar air flowing Back to Front towards the work table.
  • Supplied complete with static Finish S.S., Table top, Built in U.V. Germicidal light and cock for gas, air or vacuum line, HEPA filters and pre filter.
  • Bio Gene laminar air flow having Pre filter: synthetic, non woven, polyester fiber, retention +5 µ with high efficiency.
  • Safe opening: 200-300mm
  • Castors.
  • Power point and cord.
  • counter balanced
  • To work on 230/240 volts, 50HZ A.C. Supply.
MODEL LAF-V-22 LAF-V-32 LAF-V-42 LAF-V-62 LAF-V-82
Working Size 2’ x 2’ x 2’ 3’ x 2’ x 2’ 4’ x 2’ x 2’ 6’ x 2’ x 2’ 8’ x 2’ x 2’
Size of HEPA Filter 2’ x 2’ x 6’ 3’ x 2’ x 6’ 4’ x 2’ x 6’ 3’ x 2’ x 6’ 4’ x 2’ x 6’
No. of HEPA Filter 1 1 1 2 2
Illumination 1 x 20w 1 x 20w 2 x 40w 2 x 40w 4 x 40w
