Applications
The Sterilizer JQ Series is trusted worldwide for:
- Laboratories & Research Institutes: Sterilization of glassware, instruments, and culture media.
- Hospitals & Clinical Centers: Effective sterilization of surgical tools, dressings, and reusable instruments.
- Pharmaceutical & Biotech Units: Contamination-free sterilization of packaging materials, production equipment, and research setups.
- Food & Beverage Industries: Microbiological safety testing and sterilization of quality control tools.
- Educational Institutions: Safe sterilization of laboratory instruments used in teaching and research.
Sterilizer JQ Series Features
- Separate Steam Generator and Boiler Heating: The steam generator is separately mounted with controlled steam input, allowing precise adjustment of steam generation speed and volume. This helps reduce water consumption and extends the service life of heating components.
- Safe and Reliable Stainless Steel Lid: The sterilizer is equipped with an imported 2 mm SU304 stainless steel lid, providing excellent strength and pressure resistance while reducing the risk of corrosion and secondary contamination.
- Advanced Temperature and Pressure Control: Innovative temperature and pressure control technology ensures excellent uniformity inside the chamber, with temperature variation between different measurement points maintained below 0.5°C for reliable sterilization.
- High Measurement Accuracy: The system provides temperature measurement accuracy of up to 0.1°C and pressure measurement accuracy of up to 0.001 bar for precise monitoring and control.
- Double-Control Safety Lock Structure: Advanced mechanical and electronic double-control locking mechanisms help prevent unsafe operation and ensure enhanced operator safety throughout the sterilization cycle.
- High-Performance Vacuum System: A double-head vacuum pump provides effective vacuum performance during each vacuum pulse, improving air removal and supporting complete and uniform sterilization.
- Automatic and Manual Temperature Sensor Adjustment: Temperature sensor parameters can be adjusted automatically, while manual adjustment is also available. This enables reliable operation under different atmospheric and environmental conditions.
- Multilingual and Easy-to-Operate Interface: Multiple language options are available, allowing users to select their preferred language for convenient operation and monitoring.
- Wide Ventilation Window: The broad ventilation window design provides efficient heat dissipation, helping to accelerate heat radiation and improve the overall operating efficiency of the sterilizer.
Control
- PLC / Digital PID controller with touchscreen HMI.
- Programmable sterilization cycles with dwell time adjustment.
- LCD/LED display showing cycle status, temperature, and pressure.
- Data recording through USB or Ethernet (optional).
Construction
- Inner Chamber: SS304 / SS316 stainless steel.
- Outer Body: Powder-coated GI / Stainless steel finish.
- Insulation: High-density PUF for thermal efficiency.
- Door System: Manual / semi-automatic with safety interlocks.
- Mobility: Castor wheels for easy relocation.
Sterilizer JQ Series Technical Specifications
| Parameter |
BTI-JQA-23 |
BTI-JQA-18 |
| Model | BTI-JQA-23 | BTI-JQA-18 |
| Capacity | 23 Litres | 18 Litres |
| Voltage | 220V ±10%, 50Hz | 220V ±10%, 50Hz |
| Power | 2100 W | 1800 W |
| Sterilizing Temperature | 121°C / 134°C | 121°C / 134°C |
| Pressure Range | 15–30 psi | 15–30 psi |
| Chamber Size | 250 × 450 mm | 250 × 355 mm |
| Chamber Capacity | 23 L | 18 L |
| Drying Procedure | Vacuum Drying | Vacuum Drying |
| Display | 240 × 160 Dots LCD, Multi-Language | 240 × 160 Dots LCD, Multi-Language |
| Test Programs | Bowie & Dick Test, Helix Test, Vacuum Test | Bowie & Dick Test, Helix Test, Vacuum Test |
| Sterilization Data | Optional External Mini-Printer / USB Download | Optional External Mini-Printer / USB Download |
| Special Function | Designed to inactivate HIV, HBV, bovine spongiform encephalopathy (mad cow disease) agents and Bacillus spores | Designed to inactivate HIV, HBV, bovine spongiform encephalopathy (mad cow disease) agents and Bacillus spores |
| Safety Features | Safety Valve, Double-Control Lock System, Self-Test Alarm System | Safety Valve, Double-Control Lock System, Self-Test Alarm System |
| Water Supply System | Two Internal Water Tanks | Two Internal Water Tanks |
| Fresh Water Reservoir | 3.5 L | 3.5 L |
| Waste Water Reservoir | 5 L | 5 L |
| Instrument Containers | 5-Layer Active Pallet Rack with 3 Trays | 5-Layer Active Pallet Rack with 3 Trays |
| Net Weight | 50 kg | 47 kg |
| Packing Size | 660 × 550 × 560 mm | 660 × 550 × 560 mm |
General Technical Specifications
| Parameter |
Specification |
| Temperature Range | 121°C to 134°C |
| Pressure Range | 15–30 psi |
| Chamber Volume | 18 L / 23 L |
| Controller | Digital PID / PLC with HMI |
| Cycle Time | 15–60 minutes, Programmable |
| Power Supply | 220V AC / 50Hz |
| Safety Features | Safety Valve, Double-Control Lock System, Self-Test Alarm System |
| Drying System | Vacuum Drying |
| Data Recording | USB Download / Optional External Mini-Printer |
| Test Programs | Bowie & Dick Test, Helix Test, Vacuum Test |
The Sterilizer JQ Series is designed for reliable steam sterilization of laboratory instruments, medical equipment, glassware, and other heat- and moisture-resistant materials. It uses controlled temperature, pressure, steam, and vacuum processes to support effective sterilization.
The Sterilizer JQ Series supports standard sterilization temperatures of 121°C and 134°C. The appropriate temperature can be selected according to the type of load and sterilization requirements.
The JQ Series incorporates multiple safety features, including a double-control mechanical and electronic locking system, safety valve, self-test alarm system, and controlled temperature and pressure monitoring to help ensure safe operation.
Yes. The JQ Series is equipped with a vacuum drying system and double-head vacuum pump. The vacuum process helps remove air from the chamber and supports effective steam penetration, followed by efficient drying of sterilized materials.
Yes. The sterilizer features an LCD control interface with optional multilingual operation. Automatic and manual parameter adjustment options are available, making the system convenient for different operating environments and user requirements.
